WF laser welding machine

Model:

WF1000W, WF1500W,WF2000W

Price range

$4580.00 -$10,000.00/ Set

Laser system

IPG/Raycus/maxfiber 1000w-4000w

Rating Scale

9.9/10

Laser Welding Depth

1mm~4.0mm

Power Demand

220V/50HZ/60HZ,380V/50HZ/60HZ

Payment Terms

30% deposit, full payment after machine test

Share on facebook
Share on twitter
Share on linkedin
Share on linkedin
Share on pinterest
Share on skype
Share on reddit
Share on vk

The laser welding speed is 2-10 times faster than the traditional welding. One machine can save the cost of 2 welders a year at least.

Easy to operate, you can weld beautiful products without the traditional welding training and cerfication.

The weld seam is smooth and beautiful, reducing the subsequent grinding process, saving time and cost.

professional laser welding heads, it makes up for laser welding spot small, expand the tolerance range between the machined parts and weld width, and obtain a better weld seam

NO. Name Parameter
1 Machine model Hand-held fiber laser welding machine
2 laser power 1000W,2000W,3000W
3 laser wave length 1070 NM
4 Fiber length standard10M / Maximum 15M
5 operate mode  continuation/ modulate
6 Welding speed range 0~120 mm/s
7 Cooling chiller Industrial water chiller
8 Working environment temperature range 15~35 ℃
9 Humidity range of working environment < 70% No condensation
10 Welding thickness recommendations 0.5-3mm
11 Welding gap requirements ≤0.5mm
12 working voltage 220 V

laser welding machine
  1000w
Material Depth of fusion Penetration thickness
Stainless Steel ≤4mm ≤3mm
Mild steel/Iron ≤4mm ≤3mm
Galvanized sheet ≤3mm ≤2mm
Aluminum/brass ≤2mm ≤1mm
  1500w
Material Depth of fusion Penetration thickness
Stainless Steel ≤5mm ≤4mm
Mild steel/Iron ≤5mm ≤4mm
Galvanized sheet ≤4mm ≤3mm
Aluminum/brass ≤3mm ≤2mm

  2000w
Material Depth of fusion Penetration thickness
Stainless Steel ≤6mm ≤5mm
Mild steel/Iron ≤6mm ≤5mm
Galvanized sheet ≤5mm ≤4mm
Aluminum/brass ≤4mm ≤3mm

Laser Welding Machine Head

Automatic wire head Upward

Laser Welding Machine Bottom

Automatic Wire Head ​Downward

Laser Welding Work image
